MHD37P3Y - 49.62 HP - TEFC-IP55 - 990 RPM

Catalog #: MHD37P3Y
Model #:GH62

Details

General Purpose
Three Phase Totally Enclosed Fan Cooled (TEFC)
World Motor IEC HOSTILE DUTY™
IE3 Efficiency
Discount Symbol:
DS-3HDI
Unit Weight:
440.0
lbs
List Price Per Unit:
$7,602.00
  • Specifications
  • Technical Data
Model_Number
GH62
PRODUCT NAME
49.62 HP - TEFC-IP55 - 990
PHASETYPE
3_PHASE
MOTOR ENCLOSURE
TEFC-IP55
HORSEPOWER
49.62
KILOWATTS
37
POLES
6
NUMBER SPEEDS
1
RPM
990
RPM 2
990
HERTZ
50
VOLTS PRIMARY
230/400
VOLTS
400
VOLTS 2
230
FRME
250
SHAFT CODE
B3
MOUNTING
HORZ-FOOTED
ASSEMBLY POSITION
NA
MOTOR TYPE
ICTE
OPPOSITE END BEARING
6216-J/C3
SHAFT END BEARING
6316-J/C3
AMBIENT
40
ROTATION
DUAL
SERVICE FACTOR
1.15
STARTCAPMFD
N\A
SHIPPING WEIGHT
440
BREAKDOWN TORQUE
231
BREAKDOWN TORQUE UOM
PERCENT OF FLT
LOCKED ROTOR TORQUE
148
LOCKED ROTOR TORQUE UOM
PERCENT OF FLT
INSULATION CLASS
F
KVA CODE LETTER
F
LOCKED ROTOR AMPS
439.6
NEMA NOMINAL EFFICIENCY
93.6
FULL LOAD AMPS PRIMARY
118/68
SERVICE FACTOR AMPS PRIMARY
0/78
GH62
IHPO
08-1145
I_438252
