5562EO - 0.33 HP - TEAO - 1200 RPM

Catalog #: 5562EO
Model #:M055ESH1237012B

Details

RESCUE EcoTech® Outdoor 48 ECM
Condenser Fan
5.6" Dia. Totally Enclosed Air Over
1/3 – 1/5 HP applications
1075 or 825 RPM replacement
Discount Symbol:
DS-3ECM
Unit Weight:
10.0
lbs
List Price Per Unit:
$352.00
  • Specifications
  • Technical Data
Model_Number
M055ESH1237012B
PRODUCT NAME
.33 HP - TEAO - 1200
PHASETYPE
1_BRUSHLESS PERMANEN
MOTOR ENCLOSURE
TEAO
HORSEPOWER
.33
KILOWATTS
0.3
POLES
10
NUMBER SPEEDS
1
RPM
1200
HERTZ
60
HERTZ 2
50
VOLTS PRIMARY
208-230 V
VOLTS
208
VOLTS 2
230
FRME
48
SHAFT CODE
Y
STACK
1.375
MOTOR TYPE
FHP
OPPOSITE END BEARING
BALL
SHAFT END BEARING
BALL
AMBIENT
60
ROTATION
CCW LEAD END REV
SHIPPING WEIGHT
10
THERMAL PROTECTION
ELECTRONICALLY PROTECTED
BREAKDOWN TORQUE UOM
OZFT
LOCKED ROTOR TORQUE UOM
OZFT
INSULATION CLASS
B
FULL LOAD AMPS PRIMARY
2.5
M055ESH1237012B
FHPO
