3076 - 0.75 HP - TEAO - 1140 RPM
Catalog #: 3076
Model #:P055DJJ1603015B
![](https://mc08e511869d7d4a108a39d.blob.core.windows.net/commerce-photos/752-1.jpg)
Details
Three Phase
Commercial Condenser Fan
Open and Totally Enclosed Air Over
60C Ambient Belly Band Mount
Flat and Keyway on Shaft
Discount Symbol:
DS-3HAC
Unit Weight:
26.69
lbs
List Price Per Unit:
$485.00
- Specifications
- Technical Data
Model_Number
P055DJJ1603015B
PRODUCT NAME
.75 HP - TEAO - 1140
PHASETYPE
3_POLYPHASE
MOTOR ENCLOSURE
TEAO
HORSEPOWER
.75
KILOWATTS
0.6
POLES
6
NUMBER SPEEDS
1
RPM
1140
HERTZ
60
VOLTS PRIMARY
208-230 V
VOLTS
208
VOLTS 2
230
FRME
48
SHAFT CODE
Y
STATOR DIAMETER
5.5
STACK
4
MOUNTING
VERT SHAFT DOWN
MOTOR TYPE
FHP
OPPOSITE END BEARING
6203
SHAFT END BEARING
6203
AMBIENT
60
ROTATION
REVERSIBLE
SERVICE FACTOR
1.35
SHIPPING WEIGHT
27
THERMAL PROTECTION
AUTOMATIC RESET
BREAKDOWN TORQUE
273
BREAKDOWN TORQUE UOM
OZFT
LOCKED ROTOR TORQUE
225.4
LOCKED ROTOR TORQUE UOM
OZFT
INSULATION CLASS
B
LOCKED ROTOR AMPS
16.95
FULL LOAD AMPS PRIMARY
3.6
SERVICE FACTOR AMPS PRIMARY
4.3
P055DJJ1603015B
FHPO
V02809433
D04809447
